Amber warning beacon LED ø112(89)x46mm 20W
PRODUCT CODE: EBL59311
Amber LED warning beacon with 112mm (89mm glass) in diameter, operates at 12-24V and is bright with 20W of power. It is mounted to the surface with three screws.
– voltage: 12-24V
– power: 20W (18x LED)
– function: warning light (amber)
– installation: 3x screw
– approval: ECE R65 / EMC R10
– ingress protection (IP rating): IP67
– operating temperature: -30°C to +60°C
– 7 flash patterns
Wire diagram:
– black: negative pole “-”
– red: positive pole “+”
– yellow: apply to black wire to select/change flash pattern
– white: synchronisation
